CANADIAN
BLOWER's Model THP (Tubeaxial) Fan: The Model THP
is the belt driven tubeaxial fiberglass axial flow fan utilizing a
7-bladed
propeller. It fulfills the need for a corrosion resistant fan with more
performance capability and lower noise level. The propeller, housing,
bearing
base and inner support structures are constructed of glass reinforced
plastic.
CANADIAN
BLOWER's Model VHP (Vaneaxial) Fan: Adding a vane
section to the Model THP tubeaxial fiberglass axial flow fan converts
it to a
Model VHP vaneaxial fan for improved performance.
Fan Propeller
Design:
The THP &
VHP fan propellers are constructed using a
resin transfer method (RTM). Glass cloth is cut to various template
sizes to
form laminations which are fitted into a mold. Glass is impregnated
with “vinyl
ester” in a low-pressure injection process. The fan's propeller is
cured under
pressure in the mold, forming a monolithic structure.
Optional Fan
Accessories:
• Fiberglass
Curb Base
• Fiberglass
Stack Cap
• Companion
Flanges
• Stack Cap
Bird Screen
• OSHA Type
Inlet/Outlet Guard
• Bolted
Inspection Door
• Horizontal
Support Legs
• Exterior
Stainless Steel Hardware
The model TMF
belt driven tubeaxial fan is constructed from
corrosion-resistant FRP and utilizes fiberglass propeller for medium
performance range requirements. The standard resin used for the TMF is
resistant to a large variety of alkalis and other chemical agents. All
fiberglass parts are coated inside and outside with resin (with UV
inhibitor),
approximately 10 mils in thickness, to seal the surface and provide a
smooth
finish.
CANADIAN
BLOWER's TMF's propeller is constructed with glass
cloth impregnated with vinyl ester resin and secured to a 316 stainless
steel
fan shaft by a stainless steel retainer bold and washer. Propellers
shall be
statically and dynamically balanced to ensure quiet operation.
Design to
withstand corrosive environments, the TPF's
standard housing is fabricated with an integral inlet side mounting
flange. It
incorporates a solid FRP motor base that is reinforced with solid FRP
support
struts.
CANADIAN
BLOWER's TPF's fan propeller is constructed with
glass cloth impregnated with vinyl ester resin.
Optional Fa
Accessories:
• Stainless
Steel Hardware
• Inlet/Outlet
Guard
• Automatic
Stainless Steel or Fiberglass Shutter
• Stainless
Steel Mounting Adapter
• Fiberglass
Extension Sleeve
• Option
Fiberglass Mounting Flange
• Inlet /
Outlet Guard
Optional
Materials:
• Vinyl Ester
• Surface Veil
• Fire
Retardant Resin
